- Size: 13900mm*2500mm*3990mm
- Place of Origin: Shandong,China
- Brand Name: SINOTRUK
- Model Number: TAZ9420
- Weight: 16000.000 kg
Characteristic:
Be available with 2×20ft or 1×40ft container
Maximum lift capacity:36T
Crane point automatic balance and keep changable load capacity,high safety
With both remote control and manual control for emergency
Independent power unit is optional,can provide power by the trailer itself
Italy brand HC The electromagnetic proportional valve
Sweden brand SCANRECO remote control
Italy brand COBO electrical system components
Imported sealed components
As professional manufacturer and gold supplier,we can also manufacturer as per your request.
Please not hesitate to contact us:
Joy Liu
Sales Manager
TAIAN SYKE SPECIAL VEHICLE CO.,LTD
***************************************************************
Cellphone:0086-13853865308(Whatsapp/Viber/Wechat)
Office Tel: 0086-538-8361777
Office Fax:0086-538-8361887
Skype:joyliu615
Email:sale2@chinahowotruck.com/directfactory@163.com
Web Site: www.chinahowotruck.com/www.syke.en.alibaba.com
Office Add:3211 Kaiyuan Road,Daiyue District, Tai'an, Shandong, China
Factory Add:266 Zhongtianmen Street, Daiyue District, Tai'an, Shandong, China
***************************************************************
- Size: 13900mm*2500mm*3990mm
- Place of Origin: Shandong,China
- Brand Name: SINOTRUK
- Model Number: TAZ9420
- Weight: 16000.000 kg
Model | TAZ9420 |
Brand | SINOTRUK |
Curb Weight | 16000 kg |
Overall dimension | 13900mm*2500mm*3990mm |
Max lifting capacity | 36000kg |
Max working height | 5720mm |
Max working radius | 3900mm |
Max working pressure | 25Mpa |
Nominal flow rate | 2x40 L/min |
With remote control | Yes |
With manual control for emergency | Yes |
Fit Container size | 2×20ft or 1×40ft |
Axles | FUWA brand 13ton* 3 axles |
Tire | 12.00R20 radial tire*12 pieces |
Rim | 8.5 12pieces |
Frame | Q345 carbon steel ,CNHTC heavy duty double frame,high strength |
Suspension | Mechanical suspension |
King pin | 3.5" ,JOST90# or 50# |
Support leg | JOST brand,JT200 |
Container locks | 12 sets |
Platform | 5mm diamond platform |
Brake system | WABCO brand |
Light | LED light |
Voltage | 24V |
PLC | Language :English |
Colour | Optional |
